dji Inspire 1 V2.0 - Aircraft Assembly; Attaching Propellers


Step3:InsertthegimbalintotheGimbalLock.Ensurethewhitemarkonthegimbalisalignedwith
thewhitemarkontheleftoftheGimbalLock.Refertothepicturebelowfordetails:

Step4:Withthegimbalinplace,turntheGimbalLocktotheleft
(whenyouarefacingthenoseof
the DJI Inspire1  until it locks in the position shown in the below.Now the gimbal is
secured: 

2.AttachingthePropellers
Screwthepropellers,clockwiseforgreynutsandanti‐clockwiseforblacknuts,ontothefourmotors.Be
sureto
matchtheblackpropellernutswiththeblackdotmotors.

Important：MakesureyoursmartflightbatteryandMicro‐SDcareareinsertedcorrectly.
V2.0
)
