2017 DJI All Rights Reserved.
7
INSPIRE 2
User Manual
Battery must be fully charged before using it for the first time. Refer to "Charging the
Intelligent Flight Battery" for more information .
The aircraft cannot change to Landing Mode from Travel Mode with the gimbal camera
attached.
1MBDFUIFBJSDSBGUPOUIFTNPPUIBOESFnFDUJWFTVSGBDFFHUBCMFPSUJMFCFGPSFTXJUDIJOHCFUXFFO
the travel modes to the landing mode.
Keep your hands away from the transformation mechanism when unfolding the landing gear.
Make sure to press the battery remove button when removing the battery.
Follow these steps to enter Travel Mode: Press the power button at least 5 times then
detach the gimbal and the propellers. Place the aircraft on a smooth surface and wait
as it changes into Travel Mode, then press the Remove Battery Button and remove the
batteries.
Always ensure that the DJI Gimbal Connector 2.0 on the Inspire 2 is in the right position
when mounting, otherwise the camera will not mount.
Remove the lens cap when the Zenmuse X5S is in use.
Always power off the aircraft before removing the gimbal camera.
Press the power button
BNJOJNVNPGmWFUJNFT
Unfold the landing gear to Landing
Mode and power on
Insert the battery
pair
5 x
Mounting the Zenmuse X5S to the
aircraft (Powering off not required)
Mounting the Zenmuse X5S to the Inspire 2
1. Remove the Gimbal Cap from the Zenmuse X5S.
2. Press the gimbal and camera release button on the Inspire 2. Rotate to remove the Gimbal Cap
from the Inspire 2.
3. Align the white dot on the gimbal to the red dot on Inspire 2 and insert the gimbal.
4. Rotate the Gimbal Lock to the locked position by aligning the red dots.
2
3
4
11
