©2014 DJI. All Rights Reserved. 32
Select the following transmission mode for different video quality.
[3] Master-Slave Mode Setting
When single air system is paring with more than one ground system. Master-Slave setting is required.
Master ground system can display video and relay control signal to the aircraft; slave ground system can
only display video. Steps to setup:
A) Tap “Master-Slave” option in DJI LIGHTBRIDGE App of the master ground system, make a note of the
master ID;
B) Tap “Master-Slave” option in slave ground system, enter master ID to connect.
[4] Video Source Setting
Dual video source input mode is available when connecting air system to a DJI HD gimbal. An extra video
