dji MATRICE 30 Series Maintenance Manual

8
©
2022 DJI All Rights Reserved.
MATRICE 30
SERIES Maintenance Manual
microSD
Card
Information
1. Check if there are any foreign objects in
the microSD card slot and if the microSD is
installed correctly.
2. Check if the microSD card is working properly.
Rubber Port
Covers
1. The rubber port covers are not damaged or
loose.
Heat
Dissipation
Vents
1. The heat dissipation vents are not blocked.
The cooling fans work smoothly without noise.
Gimbal
Damping
Plate
1. The dampeners are not damaged, loose, or
aged.
2. The screws connecting the damping plate and
aircraft body are secure.

dji MATRICE 30 Series Specifications

General

Max Flight Time	41 minutes
Max Service Ceiling	7000 m
Max Ascent Speed	6 m/s
Max Descent Speed	5 m/s
Ingress Protection Rating	IP55
Max Speed	23 m/s
Operating Temperature Range	-20°C to 50°C (-4°F to 122°F)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Max Tilt Angle	35°
GNSS	GPS, GLONASS, BeiDou, Galileo
Hovering Accuracy Range (P-mode with GPS)	±0.5 m (Vertical), ±1.5 m (Horizontal)
Operating Temperature (Battery)	-20°C to 50°C (-4°F to 122°F)
Battery Charging Temperature	5° to 40° C (41° to 104° F)
Transmission Range	15 km
