INSTRUCTIONS FOR USE
Installation of the circuit breaker modules:
To place the circuit breaker modules on each side in the battery slots, insert them from the rear by sliding
them forward.
Installation of the parachute pods:
Install the two “parachute” pods on each side of the drone, covering the
pyrotechnic charges and screw in tightly.
Installation of drone batteries:
Install the two TB60 batteries normally by sliding from the rear, then
lock using the rotating “butterfly” type fixing.
FLYSAFE-M30
Version 1.05
Hardware version 1.05
09/20/2023
Slide the modules all the way forward to the stop to ensure a good connection to the connector.
The circuit breaker modules can remain in place for storage in the M350 RTK case.
