dji Mavic 2 Enterprise User Manual

Mavic 2 Enterprise User Manual
10
©
2018 DJI All Rights Reserved.
1. Antennas
Relay aircraft control and video wireless
signals.
2. Return to Home (RTH) Button
Press and hold the button to initiate RTH.
The aircraft returns to the last recorded Home
Point. Press again to cancel RTH.
3. LCD Screen
Displays the aircraft and remote controller
system status.
4. Removable Control Sticks
The removable control sticks are easy to
store. The default ight control is set to Mode
2. Set the ight control mode in DJI Pilot.
5. Flight Pause Button
Press to make the aircraft brake and hover in
place (only when GPS or Vision System are
available).
6. Control Sticks Storage Slot
For storing the control sticks.
7. Mobile Device Clamps
Securely mount your mobile device onto the
remote controller.
8. Reserve Video-Downlink Port (USB)
Connect to a mobile device for video
downlink via a standard USB cable.
9. 5D Button
The default conguration is listed below. The
conguration can be adjusted based on your
preferences in DJI Pilot.
Left: Decrease EV value.
Right: Increase EV value.
Up: Recenter gimbal/gimbal downward.
Down: Recenter gimbal/gimbal downward.
Press down: Bring up DJI Pilot Intelligent
Flight menu.
10. Flight Mode Switch
Switch between S-mode, P-mode, and
T-mode.
11. Power Button
Press once to check the current battery
level. Press once, then again, and hold to
turn on/o the remote controller.
12. C1 Button (Customizable)
The default configuration is center focus.
Adjust the conguration in DJI Pilot based
on your preferences.
13. Gimbal Dial
Controls the camera's tilt.
14. Video-Downlink/Power Port (micro USB)
Connect to a mobile device for video
linking via the RC cable. Connect to the
AC Power Adapter to charge the remote
controller battery.
15. Record Button
Press to start recording video. Press again
to stop recording.
16. Focus/Shutter Button
Press halfway to autofocus. Press once
to take photos according to the mode
selected in the DJI Pilot.
12
13
14
15
17
16
18
1
2
11
10
9
3
4
5
6
7
8

dji Mavic 2 Enterprise Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Hovering time (max)	29 min
Hovering time (min)	22 min
Maximum flight time	31 min
Maximum descent speed	3 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	200 °/sec
Operating temperature (T-T)	-10 - 40 °C
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Optical sensor size	1/2.3 \
Camera shutter speed	8-1/8000 s
Mechanical pan range	-100 - 100 °
Mechanical tilt range	-135 - 45 °
Supported file systems	FAT32, exFAT
Image formats supported	DNG, JPEG, RAW
Video formats supported	H.264, MOV, MP4, MPEG4
Maximum image resolution	4056 x 3040 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.6 °
Bitrate at maximum video resolution	100 Mbit/s
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Moving control functions	-
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	3950 mAh
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.41 A
AC adapter output voltage	17.6 V

Weight and Dimensions

Battery weight	297 g
Takeoff weight (max)	1100 g
