Mavic 2 Enterprise User Manual

Calibration Procedure

Choose an open area to carry out the following procedure.

1. Tap the System Status Bar in DJI Pilot, select “Calibrate”, and follow the on-screen instructions.

2. Hold the aircraft horizontally and rotate it 360 degrees. The Aircraft Status Indicator will turn solid

green.

3. Hold the aircraft vertically, with its nose pointing downward, and rotate it 360 degrees around a

vertical axis.

4. If the Aircraft Status Indicator blinks red, the calibration has failed. Change your location and try the

calibration procedure again.

Horizontal Calibration

Vertical Calibration

The aircraft can take off immediately once calibration is complete. If you wait more than three

minutes to take off after calibration, you may need to calibrate again. It is possible that another

compass interference warning will appear while the aircraft is on the ground. This indicates

that the current location is not suitable for flying the aircraft, due to the level of magnetic

interference.

Firmware Updates

Use DJI Pilot or DJI Assistant 2 for Mavic to update the aircraft rmware.

Using DJI Pil

When you connect the aircraft or remote controller to DJI Pilot, you will be notied if a new rmware

update is available. To start updating, connect your mobile device to the internet and follow the on-

screen instructions. Note that you cannot update the rmware if the remote controller is not linked to the

aircraft.

Using DJI Assistant

2 for Mavic

The USB-C port is used when connecting the aircraft to a computer to update rmware.

Follow the instructions below to update the rmware through DJI Assistant 2 for Mavic:

Questions and Answers:

Need help?

Do you have a question about the dji Mavic 2 Enterprise and is the answer not in the manual?

dji Mavic 2 Enterprise Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Hovering time (max)	29 min
Hovering time (min)	22 min
Maximum flight time	31 min
Maximum descent speed	3 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	200 °/sec
Operating temperature (T-T)	-10 - 40 °C
Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Optical sensor size	1/2.3 \
Camera shutter speed	8-1/8000 s
Mechanical pan range	-100 - 100 °
Mechanical tilt range	-135 - 45 °
Supported file systems	FAT32, exFAT
Image formats supported	DNG, JPEG, RAW
Video formats supported	H.264, MOV, MP4, MPEG4
Maximum image resolution	4056 x 3040 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.6 °
Bitrate at maximum video resolution	100 Mbit/s
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Moving control functions	-
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	3950 mAh
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.41 A
AC adapter output voltage	17.6 V
