dji MAVIC 3E User Manual

DJI Mavic 3E/3T User Manual
14
©
2022 DJI All Rights Reserved.
scale power transmission stations or mobile base stations, and broadcasting towers.
The aircraft may behave abnormally or lose control when flying in areas with too much
interference. Return to the Home Point and land the aircraft if prompted to do so in DJI
Pilot 2.
Vision Systems and Infrared Sensing System
DJI Mavic 3E/3T is equipped with both an Infrared Sensing System and Horizontal
Omnidirectional (Forward, Backward, Lateral), Upward, and Downward Vision Systems.
The Upward and Downward Vision Systems consist of two cameras each, and the
Forward, Backward, and Lateral Vision Systems consist of four cameras in total.
The Infrared Sensing System consists of two 3D infrared modules. The Downward
Vision System and Infrared Sensing System help the aircraft maintain its current
position, hover more precisely, and fly indoors or in other environments where GNSS is
unavailable.
In addition, the Auxiliary Bottom Light located on the underside of the aircraft improves
visibility for the Downward Vision System in weak light conditions.
Detection Range
Forward Vision System
Precision Measurement Range: 0.5-20 m; FOV: 90° (horizontal), 103° (vertical)
Backward Vision System
Precision Measurement Range: 0.5-16 m; FOV: 90° (horizontal), 103° (vertical)
Lateral Vision System
Precision Measurement Range: 0.5-25 m; FOV: 90° (horizontal), 85° (vertical)
Upward Vision System
Precision Measurement Range: 0.2-10 m; FOV: 100° (front and back), 90° (left and right)
Downward Vision System
Precision Measurement Range: 0.3-18 m; FOV: 130° (front and back), 160° (left and right).
The Downward Vision System works best when the aircraft is at an altitude of 0.5 to 30 m.
Horizontal Omnidirectional Vision System
Infrared
Sensing System
Auxiliary Bottom Light
Downward Vision System
Upward Vision System
Horizontal Omnidirectional
Vision System

dji MAVIC 3E Specifications

General

Effective Pixels	20 MP
Max Flight Time	46 minutes
Max Transmission Range	15 km
Max Wind Resistance	12 m/s
Aircraft Type	Quadcopter
Max Takeoff Weight	920 g
Diagonal Distance	380.1 mm
Max Ascent Speed	8 m/s
Max Descent Speed	6 m/s
Max Horizontal Speed	21 m/s
Max Flight Distance	32 km
Max Tilt Angle	35°
GNSS	GPS+Galileo+BeiDou
Internal Storage	8 GB
Max Speed	21 m/s
Gimbal	3-axis (tilt, roll, pan)
Battery Capacity	5000 mAh
Camera Sensor	4/3 CMOS
Obstacle Sensing	Omnidirectional
Dimensions (Folded without propellers)	221×96.3×90.3 mm
Dimensions (Unfolded without propellers)	347.5×283×107.7 mm
Operating Temperature	-10° to 40° C
Hovering Accuracy Range	Vertical: ±0.1 m (with vision positioning); ±0.5 m (with GNSS positioning), Horizontal: ±0.3 m (with vision positioning)
Storage Temperature	-20° to 45° C
Camera - Zoom	Yes, Hybrid Zoom
Charging Time	96 minutes
