dji MAVIC 3E - Page 83

DJI Mavic 3E/3T User Manual
83
©
2022 DJI All Rights Reserved.
Charging Type Recommended to be charged with the included DJI USB-C Power
Adapter (100W) or USB charger at 12 V or 15 V
Charging Time Approx. 1 hour 30 minutes (with the included DJI USB-C Power
Adapter (100W) only charging the remote controller or a USB
charger at 15 V)
Approx. 2 hours (with a USB charger at 12 V)
Operating Time Approx. 3 hours
Rated Power 12 W
Storage Capacity Internal Storage (ROM): 64 GB
Support microSD card to expand capacity
Video Output Port Mini HDMI port
Operating Temperature
Range
-10° to 40° C (14° to 104° F)
Storage Temperature -30° to 60° C (-22° to 140° F) (within one month)
-30° to 45° C (-22° to 113° F) (one to three months)
-30° to 35° C (-22° to 95° F) (three to six months)
-30° to 25° C (-22° to 77° F) (more than six months)
Charging Temperature 5° to 40° C (41° to 104° F)
GNSS GPS + Galileo + GLONASS
Dimensions Antennas folded and controller sticks unmounted:
183.27×137.41×47.6 mm
Antennas unfolded and controller sticks mounted:
183.27×203.35×59.84 mm
Weight Approx. 680 g
Model RM510B
Video Transmission
System
DJI O3 Enterprise Transmission
Max Transmission
Distance (unobstructed,
free of interference)
[3]
15 km (FCC), 8 km (CE/SRRC/MIC)
Operating Frequency
[2]
2.400-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC)
Antenna 4 Antennas, 2T4R
Wi-Fi
Protocol 802.11 a/b/g/n/ac/ax
Support 2×2 MIMO Wi-Fi
Operating Frequency
[2]
2.400-2.4835 GHz, 5.150-5.250 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)
Bluetooth
Protocol Bluetooth 5.1
Operating Frequency 2.400-2.4835 GHz
Transmitter Power (EIRP) <10 dBm
