dji MAVIC 3E User Manual

DJI Mavic 3E/3T User Manual
9
©
2022 DJI All Rights Reserved.
Preparing the Remote Controller
1. Use the provided charger to charge the remote controller via the USB-C port to activate
the battery.
2. Remove the control sticks from the storage slots on the remote controller and screw
them into place.
3. Unfold the antennas.
• Make sure to unfold the front arms before unfolding the rear arms.
• Make sure the gimbal protector is removed and all arms are unfolded before powering
on the aircraft. Otherwise, it may affect the aircraft self-diagnostics.
• Attach the gimbal protector when the aircraft is not in use. Adjust the camera to the
horizontal position, then cover the vision system with the gimbal protector. Note, align
the positioning holes, and then press the buckle to complete the installation.

dji MAVIC 3E Specifications

General

Effective Pixels	20 MP
Max Flight Time	46 minutes
Max Transmission Range	15 km
Max Wind Resistance	12 m/s
Aircraft Type	Quadcopter
Max Takeoff Weight	920 g
Diagonal Distance	380.1 mm
Max Ascent Speed	8 m/s
Max Descent Speed	6 m/s
Max Horizontal Speed	21 m/s
Max Flight Distance	32 km
Max Tilt Angle	35°
GNSS	GPS+Galileo+BeiDou
Internal Storage	8 GB
Max Speed	21 m/s
Gimbal	3-axis (tilt, roll, pan)
Battery Capacity	5000 mAh
Camera Sensor	4/3 CMOS
Obstacle Sensing	Omnidirectional
Dimensions (Folded without propellers)	221×96.3×90.3 mm
Dimensions (Unfolded without propellers)	347.5×283×107.7 mm
Operating Temperature	-10° to 40° C
Hovering Accuracy Range	Vertical: ±0.1 m (with vision positioning); ±0.5 m (with GNSS positioning), Horizontal: ±0.3 m (with vision positioning)
Storage Temperature	-20° to 45° C
Camera - Zoom	Yes, Hybrid Zoom
Charging Time	96 minutes
