Introduction

DJI

Mic is a dual channel wireless microphone system, including two transmitters and one receiver,

which is able to record two sound sources simultaneously at a distance of up to 250 m*. The

transmitter has a built-in omnidirectional microphone, supports the use of an external microphone,

and can be clipped to clothing or any place close to a sound source. With the internal 8 GB

storage, DJI Mic is able to record audio for up to 14 hours**.

The receiver boasts an OLED touchscreen, on which users can view the real-time volume, wireless

signal strength, gain, recording modes, and more. By utilizing the expansion port, the receiver can

be connected to a camera or mobile phone to provide high quality audio. The receiver can also

be connected to a computer to use as a microphone and with the monitor port the audio can be

monitored in real time. The charging case provided is able to charge the transmitters and receiver

simultaneously and link them automatically.

* Tested in an obstruction-free outdoor environment.

** Tested with a 48,000Hz sampling rate and 24-bit mono WAV audio format.

DJI Mic Transmitter

4 5 76 8 9

System Status Indicator

Indicates the connection status with the receiver and the battery level of the transmitter.

Blinking Pattern Descriptions

Connection Status

Solid on Connected with the receiver

Blinks slowly Disconnected from the receiver

Blinks quickly Linking

Blinks red and green alternatively Firmware updating

Battery Level Descriptions

Solid green Battery Level ≥20%

Solid red Battery Level<20%

Battery Level During Charging

Blinks green slowly Battery level: 0~25%

Blinks green twice Battery level: 26~50%

Blinks green three times Battery level: 51~75%

Blinks green four times Battery level: 76~100%

Off Fully charged
