dji N3 - Mounting the LED Module; Mounting the PMU Module

N3
User Manual
©
2016 DJI All Rights Reserved.
13
Mounting the PUM Module
Mount the PMU module to an unobstructed position on the bottom of the aircraft’s upper plate for heat
dissipation.
PMU
Mounting the LED Module
Mount the LED module in a position to ensure it remains visible during flight. The LED bracket
included can be used to x the LED module onto the aircraft.
