Firmware Update

Use DJI Mimo to update the DJI OM 5 firmware. It takes approximately three minutes to

complete an update.

How to Update

Before starting an update, make sure that the battery level is at least 15% (at least two battery

level indicators illuminated). Connect DJI OM 5 to your mobile device and launch DJI Mimo.

You will be prompted if a new rmware update is available. To start updating, connect the

mobile device to the internet and follow the on-screen instructions.

Do not exit DJI Mimo while updating the rmware. Pay attention to on-screen prompts. The

system status indicator will blink green and red alternatively and become solid green once

the rmware update has completed successfully.

If an update is unsuccessful, restart DJI OM 5 and DJI Mimo, reconnect the Bluetooth, and

retry.

Storage

DJI OM 5 is designed to be folded for easier storage and transportation. Make sure to fully

retract the built-in extension rod and fold the OM 5 after powering off. Rotate the pan and tilt

axis as shown and fold the gimbal. The mark of the axis arm should slot into the hole on the

handle. Rotate the pan axis as shown.

Questions and Answers:

Need help?

Do you have a question about the dji OM 5 and is the answer not in the manual?

dji OM 5 Specifications

General

Bluetooth	Yes
Bluetooth version	5.0
Type	Smartphone camera stabilizer
Material	-
Mounting	1/4\
Product color	Gray
Maximum device depth	10 mm
Maximum device width	84 mm
Minimum device depth	6.9 mm
Minimum device width	67 mm
Charging time	1.5 h
Operating time	6.4 h
Battery voltage	8.8 V
Battery capacity	1000 mAh
Operating temperature (T-T)	0 - 40 °C
Mechanical pan range	-161.12 - 172.08 °
Mechanical roll range	-127.05 - 208.95 °
Mechanical tilt range	-101.46 - 229.54 °
