dji Phantom 2 Vision + Manual

©2014 DJI Innovations. All Rights Reserved.39 |
Reset
B u tto n
1.
Power on the camera and range extender.
2. Approximately 30 seconds later, press the resetbutton on the range extender with a thin object until the
SYSTEM Indicator turn off.The range extenderwill then restart automatically.
3. Approximately 30 seconds later, the SYSTEM Indicator should start to blink green, which indicates the
range extender is now ready to be bound.
4. (Fig.1)Run the DJI VISION App->Settings->General->Binding. (Fig.2) Select’Scan the QR Code’ to scan the
camera QR c ode on the product packaging. (Fig.3) Get the camera SSID (E.g. FC200_0xxxxx) and the MAC
address. Users can also skip the scan and enter the camera MAC address directly (Fig.4, Fig.5), the MAC
address can be found on the label on camera.
5. Select the tick on the top right corner. The range extendershould automatically restart. The binding
procedure is now co m p le t e d.
二维码
示例
DO NOT push the reset button of the range extender unless you are ready to rebind the range
extender and the camera! This will unbind your camera and you must follow the steps above to
rebind.
If both the PHANTOM 2 VISION+ aircraft and range extender are powered on and working normally,
you will be able to find the SSID on the Wi-Fi list of the mobile device.
（
1
）
The QR code is located on the packaging of the PHANTOM 2 VISION+. If you cannot find the QR

dji Phantom 2 Vision + Specifications

General

Camera Resolution	14 MP
Flight Time	25 minutes
Max Speed	15 m/s
Max Ascent Speed	6 m/s
Max Descent Speed	2 m/s
GPS	Yes
Gimbal	3-axis
Battery Capacity	5200 mAh
Diagonal Motor-to-Motor Distance	350 mm
Transmitter Frequency	2.4 GHz
Battery Voltage	11.1 V
Video Resolution	1080p at 30fps, 720p at 60fps
Control Range	700 meters
Battery	3S LiPo
Operating Temperature	-10°C to 50°C
Video Recording Modes	1080p30 / 720p60
Transmitter Range	700 meters
Max Flight Distance	700 meters
Weight	1242 g
Charging Time	90 minutes
