dji Phantom 2 Vision + Manual

©2014 DJI Innovations. All Rights Reserved.38 |
Low battery capacity warning
During flight, when the range extender is low battery capacity, a warning will appear in the camera page of DJI
VISION App.
6.3Rename SSID of Range Extender
For easier acknowledge the SSID of your range extender, users can rename SSID of range extender.
1.
Tap “Rename SSID of Range Extender” in the Settings page. Enter a new name SSID name (e.g. Phantom_2
VISION+) in the textbox.
2. Tap
,and users will be asked to enter the last six numbers of MAC address on range extender to confirm
the modification.
3. Tap“OK” to confirm and the range extendershould automatically restart. Approximately 30 seconds later,
the network named of Phantom_2 VISION PLUS can be searched in theWi-Fi list of your mobile device.
Select and connect the renamed network, DJI VISION App can be used.
6.4 Binding theCamera &Range Extender
If the connection of PHANTOM 2 VISION+ and range extender is lost, or one of them needs to be repaired or
replaced, a camera and range extender binding will need to be performed via the DJI VISIONApp.

dji Phantom 2 Vision + Specifications

General

Camera Resolution	14 MP
Flight Time	25 minutes
Max Speed	15 m/s
Max Ascent Speed	6 m/s
Max Descent Speed	2 m/s
GPS	Yes
Gimbal	3-axis
Battery Capacity	5200 mAh
Diagonal Motor-to-Motor Distance	350 mm
Transmitter Frequency	2.4 GHz
Battery Voltage	11.1 V
Video Resolution	1080p at 30fps, 720p at 60fps
Control Range	700 meters
Battery	3S LiPo
Operating Temperature	-10°C to 50°C
Video Recording Modes	1080p30 / 720p60
Transmitter Range	700 meters
Max Flight Distance	700 meters
Weight	1242 g
Charging Time	90 minutes
