2Camera Page
[1] Return
- Return to the preview page
[2]Camera Pitch Control
- Pitch Control switch is white whenin normal mode, tap once the switch will be highlight and enter
into the Accelerometer Sensor Mo de .Tap once again to return to normal mode.
Normal Mode
Tap up arrow to pitch camera u pwards and down arrow to pitch downwards. Green slider indicates
current camera pitch.
Gimbal pitch control (Normal M ode )
Gimbal pitch movement
Accelerometer Sensor Mode
Tap the camera pitchswitch once to enter into Accelerometer Sensor Mode. The gimbal pitch movement and
aircraft yaw movement will be controlledby moving your mobile device.
（
1
）
Hold your mobile device carefully in Accelerometer Sensor Mode as any movement of it will
change the gimbal pitch angle and aircraft azimuthan g le real timely.
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
