Gimbal Camera

Camera and Gimbal

Camera

Pro e

The Phantom 4 Pro / Pro+ camera uses 1-inch CMOS sensor to capture video (up to 4096×2160p at

60fps) and 20 megapixel stills. Videos can be stored in either MOV or MP4 formats. Available picture

shooting modes include burst, continuous, and time-lapse mode. A live preview of what the camera sees

can be monitored on the connected mobile device via the DJI GO 4 app.

The Phantom 4 Pro / Pro+ supports the capture of 4K at 60fps. Both H.265 and H.264 are supported, w th

a maximum video bitrate of 100 Mbps.

The 20 megapixel photos taken by Phantom 4 Pro / Pro+ is the result of the application of advanced

image processing technique. A variety of shooting modes deliver a better shooting experience. A

mechanical shutter with a 1/2000 max speed eliminates rolling shutter distortion when capturing stills of

fast moving objects.

Camera M cro SD Card S ot

To store your photos and videos, insert the Micro SD card into he slot as shown below before

turning on the Phantom 4 Pro / Pro+. The Phantom 4 Pro / Pro+ comes with a 16 GB Micro SD card

and supports Micro SD cards up to 128 GB. A UHS-1 and above Micro SD card is recommended

due to their fast read and write speeds that support hig -resolution video data.

Do not emove the Micro SD card from the Phantom 4 Pro / Pro+ when it is shooting.

To ensure the stability of the camera system, single video recordings are capped at 30 minutes.

Camera Data Port (M cro USB)

Turn on the Phantom 4 Pro / Pro+ and connect a USB cable to the Camera Data Port to download photos

and videos to a computer. The camera Micro SD card cannot be read when DJI Assistant 2 is being

used.

www.carlosmendoza.com.mx

Questions and Answers:

Need help?

Do you have a question about the dji PHANTOM 4 PRO+ and is the answer not in the manual?

dji PHANTOM 4 PRO+ Specifications

General

Type	Quadcopter
Backlight	Yes
Certification	CE, FCC
Product color	White
Construction type	Ready-to-fly (RTF)
Operating time	30 min
Battery voltage	15.2 V
Battery capacity	5870 mAh
Transmitter battery capacity	6000 mAh
Number of batteries supported	1
Maximum speed	20 m/s
Frequency band	2.4 - 2.483 GHz
Number of axis	3
Number of rotors	4 rotors
Integrated sensors	Infrared (IR) sensor
Maximum tilt angle	42 °
Maximum ascent speed	6 m/s
Maximum descent speed	4 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	7000 m
Number of obstacle sensors	5
Number of propeller blades	2
Maximum pitch angular velocity	90 °/sec
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter output voltage	17.4 V
Power consumption (transmitter) (max)	1200 mA
Equivalent Isotropically Radiated Power (EIRP)	17 dBmW
Operating temperature (T-T)	-10 - 40 °C
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1 \
Camera shutter speed	8 - 1/8000 s
Supported video modes	720p, 1080p, 2160p
Image formats supported	DNG, MJPEG, RAW
Video formats supported	AVC, H.264, H.265, MOV, MP4, MPEG4
Live view frequency band	5.8 GHz
Maximum image resolution	5472 x 3078 pixels
Maximum video resolution	4096 x 2160 pixels
Field of view (FOV) angle	84 °
Bitrate at maximum video resolution	100 Mbit/s
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Flight modes	Altitude hold mode, Draw mode, Follow Me mode, TapFly mode, Tracking mode
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Cables included	AC, Micro-USB, USB
Memory card included	MicroSD
Included memory card size	16 GB
Motor type	Brushless
Built-in processor	-
