dji Phantom 4 RTK Quick Stark Guide

Remo
te Controller
Thepowe
rfulremotecontrollerofthePhantom4RTKhasatransmissionrangeextendingupto4.3mi(7km)*.Itfeatures
physicalbuttonsanddialstocontrolcameratilt,photocaptureandvideorecording.Builtintotheremotecontrolleris
DJIOCUSYNC
TM
,providingaliveHDviewfr
omthePhantomcameradirectlyonthedisplay.Dualfrequencysupportmakes
theHDvideodownlinkmorestable.Replaceablebatteriesandantennasoftheremotecontrollermakeiteasyfordaily
operationandmaintenance.
Thedefa
ultflightcontrolisknownasMode2.Theleftstickcontrolstheaircraft’saltitudeandheading ,whiletherightstick
controlsitsforward,backward,leftandrightmovements.Thegimbaldialcontrolsthecamera’stilt.

*Theremotecontrollerisabletoreachitsmaximumtransmissiondistance(FCC)inawideopenareawithno
Electro‐MagneticInterference,andatanaltitudeofabout400f eet(120meters).

19PauseButt
on
20CameraSettingsDial
21C1Button(customizable)
22C2Button(customizable)
23BatteryCompartmentCover
24BatteryCompartmentCoverLock
25RemoteControllerBackCover
10BatteryLevelLEDs
11MicroSDCardSlot
12RTHStatusLED
13RTHButton
14GimbalDial
15RecordButton
16FlightModeSwitch
17Sleep/WakeButton
18ShutterButton
1Antennas
2DisplayDevice
3Speaker
4ControlSticks
5LanyardAttachment
6PowerButton
7StatusLED
8USB‐CPort
93.5mmAudioPort

dji Phantom 4 RTK Specifications

General

Type	Quadcopter
Product color	White
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	16.1 m/s
Frequency band	2.4 - 2.483 GHz
Number of rotors	- rotors
Maximum flight time	30 min
Maximum ascent speed	6 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Horizontal hover accuracy	0.1 m
Maximum operating distance	- m
Megapixel	20 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Camera shutter speed	8 - 1/8000 s
Image formats supported	JPEG
Video formats supported	H.264
Maximum image resolution	5472 x 3648 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	84 °
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Number of waypoints	199
Moving control functions	Downward, Forward
Operating frequency	2400 - 2483/5725 - 5850 MHz
Battery voltage	15.2 V
Battery capacity	5870 mAh
Transmitter battery capacity	6000 mAh
Output power	160 W
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, Micro-USB, USB Type-C
Memory card included	MicroSD
Included memory card size	16 GB

Weight and Dimensions

Battery weight	468 g
