dji Phantom 4 RTK Quick Stark Guide

Using Phantom 4 RTK
1.MounttheRem
oteControllerBattery
An external changeable Intelligent Battery is used for the remote controller, which is convenient for
long‐termoperation.
SlidetheBatteryCompartmentCoverLockonbackoftheremotecontroller.ThenmounttheIntelligent
Batteryintothecompartmentandpushittothetopposition.Finally,closethecover.
Press and hold the B
attery Release Button and push the battery down to remove it from the
compartment.
2.ChecktheBatteryLevels

Pressoncetocheckthebatterylevel.Pressonce,thenag ainandholdtoturnon/off.
3.ChargetheBatteries

●Makesuretofullychargethebatteriesinfirst‐timeuse.
4.PreparetheRemoteController
Batte
ryReleaseButton
Low→ High
Pow
e
rOutlet
100~240V
Low→ High

dji Phantom 4 RTK Specifications

General

Type	Quadcopter
Product color	White
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	16.1 m/s
Frequency band	2.4 - 2.483 GHz
Number of rotors	- rotors
Maximum flight time	30 min
Maximum ascent speed	6 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Horizontal hover accuracy	0.1 m
Maximum operating distance	- m
Megapixel	20 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Camera shutter speed	8 - 1/8000 s
Image formats supported	JPEG
Video formats supported	H.264
Maximum image resolution	5472 x 3648 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	84 °
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Number of waypoints	199
Moving control functions	Downward, Forward
Operating frequency	2400 - 2483/5725 - 5850 MHz
Battery voltage	15.2 V
Battery capacity	5870 mAh
Transmitter battery capacity	6000 mAh
Output power	160 W
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, Micro-USB, USB Type-C
Memory card included	MicroSD
Included memory card size	16 GB

Weight and Dimensions

Battery weight	468 g
