DJI RC Pro User Manual
6
©
2021 DJI All Rights Reserved.
20. Air Vent
Used for heat dissipation. Do not block the air vent during usage.
21. Control Sticks Storage Slot
For storing the control sticks.
22. Customizable C1 Button
Switch between recentering the gimbal and pointing the gimbal downward. The function can be set
in DJI Fly.
23. Speaker
Outputs sound.
24. Customizable C2 Button
Press once to turn the Auxiliary Bottom Light on or o. The function can be set in DJI Fly.
25. Air Intake
Used for heat dissipation. DO NOT cover the air intake during use.
20
24
22
23
25
21

Other manuals for dji RC Pro

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji RC Pro and is the answer not in the manual?

dji RC Pro Specifications

General IconGeneral
CompatibilityMavic 3
Product colorBlack
Brand compatibilityDJI
Operating temperature (T-T)-10 - 40 °C
Quantity per pack1 pc(s)
Built-in displayYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Transmission distance15000 m
Battery life3 h
Battery typeBuilt-in battery
Battery voltage7.2 V
Battery capacity5000 mAh
Battery recharge time2 h
Weight and Dimensions IconWeight and Dimensions
Depth137.41 mm
Width183.27 mm
Height47.6 mm
Weight680 g
