dji RSC 2 User Manual

DJI RSC 2
User Manual
10
© 2020 DJI OSMO All Rights Reserved.
2. Balancing Depth for the Tilt Axis
a. Rotate the tilt axis so that the camera lens is pointing forward. Toggle the lever to
the unlocked position
1
.
b. Check to make sure the camera is not front or back-heavy. If front-heavy, move the
camera backward
2
. If back-heavy, move the camera forward
2
.
c. Toggle the lever to the locked position. The tilt axis is balanced when the camera is
steady while tilted up or down by 45°.
d. Lock the tilt axis.
3. Balancing the Roll Axis
a. Unlock the roll axis. Loosen the knob on the roll arm
1
.
b. Check the direction in which the roll motor swings. If the camera rotates to the left,
move the camera to the right
2
. If the camera rotates to the right, move the camera
to the left
2
.
c. Tighten the knob. The roll axis is balanced when the camera is steady.
d. Lock the roll axis.
1
2
1
2

dji RSC 2 Specifications

General

Type	Hand camera stabilizer
Foldable	Yes
Material	-
Mounting	1/4\
Applicability	Universal
Product color	Black
Number of axis	3
Tilt angle range	0 - 360 °
Angle of rotation	360 °
Compatible products	Sony: A9/A9 Ⅱ, A7M III/A7S III/A7R IV/A7R III/A7R II/A7S II/A7M II, A7S, A6300/A6100/A6400, A6600/A6500; Panasonic: GH5S/G9, GH5, GH4/GH3, S1, S1H; Nikon: Z6/Z7, Z50, D850, D780, D6/D5; Canon: EOS R5/EOS R6, EOS RP, 5D MK III/5D MK IV/5DS R, 6D MK II/90D, 80D/6D, EOS-1DX Mark II/EOS-1DX Mark III, EOS 77D; FUJIFILM: X-T3/X-T2, X-T4, X-H1, X-T30/X-T20/X-E3; Black magic design: BMPCC 4K, BMPCC 6K; Z CAM: Z CAM E2; Olympus: OM-D E-M1 II;
Maximum weight capacity	3 kg
Bluetooth version	5.0
Battery type	18650
Charging time	2 h
Operating time	14 h
Battery voltage	7.2 V
Battery capacity	3400 mAh
Operating temperature (T-T)	-20 - 45 °C
Cables included	USB
Package depth	275 mm
Package width	330 mm
Package height	103 mm
Package weight	1950 g

Weight and Dimensions

Depth	175 mm
Width	185 mm
Height	400 mm
Weight	1216 g
Dimensions folded (WxDxH)	260 x 210 x 75 mm
