16
© 2020 DJI OSMO All Rights Reserved.
Operations
Activating DJI RSC 2
DJI RSC 2 needs to be activated through the Ronin app before using for the rst time.
1. Press and hold the power button to power on the gimbal.
2. Enable Bluetooth on your mobile device and launch the Ronin app. Once detected in
the list of Bluetooth devices, select DJI RSC 2 and input the default Bluetooth password:
12345678. Make sure you are connected to the internet and follow the on-screen
instructions to activate DJI RSC 2. Note that a DJI account is required during activation.
Screen Operation
Home
: indicates the current user prole. Users can set and save three user proles: M1,
M2, and M3.
: indicates the DJI RavenEye Image Transmission System is connected.
: indicates Sport mode is enabled.
: indicates a camera control cable is connected.
: indicates the battery is being charged.
: displays the current battery level of the gimbal.
Press the side dial to enter the menu, turn the side dial to scroll through the options, and
press conrm to select. Press the back button to go back to the previous menu.

Other manuals for dji RSC 2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji RSC 2 and is the answer not in the manual?

dji RSC 2 Specifications

General IconGeneral
TypeHand camera stabilizer
FoldableYes
Material-
Mounting1/4\
ApplicabilityUniversal
Product colorBlack
Number of axis3
Tilt angle range0 - 360 °
Angle of rotation360 °
Compatible productsSony: A9/A9 Ⅱ, A7M III/A7S III/A7R IV/A7R III/A7R II/A7S II/A7M II, A7S, A6300/A6100/A6400, A6600/A6500; Panasonic: GH5S/G9, GH5, GH4/GH3, S1, S1H; Nikon: Z6/Z7, Z50, D850, D780, D6/D5; Canon: EOS R5/EOS R6, EOS RP, 5D MK III/5D MK IV/5DS R, 6D MK II/90D, 80D/6D, EOS-1DX Mark II/EOS-1DX Mark III, EOS 77D; FUJIFILM: X-T3/X-T2, X-T4, X-H1, X-T30/X-T20/X-E3; Black magic design: BMPCC 4K, BMPCC 6K; Z CAM: Z CAM E2; Olympus: OM-D E-M1 II;
Maximum weight capacity3 kg
Bluetooth version5.0
Battery type18650
Charging time2 h
Operating time14 h
Battery voltage7.2 V
Battery capacity3400 mAh
Operating temperature (T-T)-20 - 45 °C
Cables includedUSB
Package depth275 mm
Package width330 mm
Package height103 mm
Package weight1950 g
Weight and Dimensions IconWeight and Dimensions
Depth175 mm
Width185 mm
Height400 mm
Weight1216 g
Dimensions folded (WxDxH)260 x 210 x 75 mm
