DJI RSC 2

User Manual

Operation Modes

There are four operation modes for DJI RSC 2: Upright, Underslung, Flashlight, and

Briefcase.

Using ActiveTrack 3.0

When tracking a person, it is recommended to select and conrm the person in the center of

the camera view by pressing the trigger once. When tracking an object, it is recommended

to select and conrm the object by dragging a box around it in order to recognize the object

better. The gimbal begins to track after recognizing the object successfully.

The appropriate speed should be set when using ActiveTrack. Subjects may be lost if the

speed is set too high and the stabilization may be affected if the speed is set too low.

For optimal performance, it is recommended to set the ActiveTrack speed to 20 when using a

lens with a 24 mm equivalent focal length (tested with Sony α7 III). Increase the ActiveTrack

speed when using a lens with an equivalent focal length less than 24 mm. Decrease the

ActiveTrack speed when using a lens with an equivalent focal length more than 24 mm.

Tap

to use Virtual Joystick and Force Mobile.

Refer to the DJI Ronin RavenEye Image Transmission System User Guide for

more information.

Upright mode: Upright mode is enabled after powering on the gimbal.

Underslung mode: enter sleep mode when the gimbal is in Upright mode and turn DJI

RSC 2 upside down and rotate the roll axis 180°. Underslung mode is enabled after DJI

RSC 2 exits from sleep mode.

Underslung ModeUpright Mode

Other manuals for dji RSC 2

Questions and Answers:

Need help?

Do you have a question about the dji RSC 2 and is the answer not in the manual?

General

Type	Hand camera stabilizer
Foldable	Yes
Material	-
Mounting	1/4\
Applicability	Universal
Product color	Black
Number of axis	3
Tilt angle range	0 - 360 °
Angle of rotation	360 °
Compatible products	Sony: A9/A9 Ⅱ, A7M III/A7S III/A7R IV/A7R III/A7R II/A7S II/A7M II, A7S, A6300/A6100/A6400, A6600/A6500; Panasonic: GH5S/G9, GH5, GH4/GH3, S1, S1H; Nikon: Z6/Z7, Z50, D850, D780, D6/D5; Canon: EOS R5/EOS R6, EOS RP, 5D MK III/5D MK IV/5DS R, 6D MK II/90D, 80D/6D, EOS-1DX Mark II/EOS-1DX Mark III, EOS 77D; FUJIFILM: X-T3/X-T2, X-T4, X-H1, X-T30/X-T20/X-E3; Black magic design: BMPCC 4K, BMPCC 6K; Z CAM: Z CAM E2; Olympus: OM-D E-M1 II;
Maximum weight capacity	3 kg
Bluetooth version	5.0
Battery type	18650
Charging time	2 h
Operating time	14 h
Battery voltage	7.2 V
Battery capacity	3400 mAh
Operating temperature (T-T)	-20 - 45 °C
Cables included	USB
Package depth	275 mm
Package width	330 mm
Package height	103 mm
Package weight	1950 g
