Overview
1. Power Button
2. Battery LED Indicators
3. Charging Station Power Level LEDs
4. USB Port
5. Power Port
Usage
Connected to an External Power Source
When connected to an external power source, the Charging Station can charge
itself, Intelligent Flight Batteries, and other compatible equipment. Follow the
instructions below to use the Charging Station.
6. Firmware Update Port (Micro USB)
7. Securing Board Switch
8. Charging Contact
9. Battery Slot Track
10. Securing Board
1
8
7
10
4
6
5
9
3
2
LED1 2 3 4
