7
EN
1 2 3
6
7
8
9
10
11
12
13
14
21
20
19
18
17
1516 14
22
4 5
1. View Type
2. Camera Parameters
3. Auto Exposure Lock
4. Focus Mode
5. Storage Info
6. Exposure Settings
7. IMU Calibration Status
8. Camera Settings
9. Recording Mode (Shutter/Video
Record/Point Cloud Record)
DJI Pilot 2 App
In DJI Pilot 2 app, users can perform a flight mission or use Manual mode to record point cloud
data, preview the model and take a quick view of 3D point cloud effect.
4. Left Dial: adjust the tilt of the
gimbal.
5. Record Button: press once to start
or stop recording.
6. Focus/Shutter Button: press the
button halfway down for autofocus
and all the way down to take a photo.
7. Right Dial: adjust the pan of the gimbal.
* The function of these buttons can be customized in the DJI Pilot 2 app.
3
4
5
6
7
10. Shooting Button
(Shutter/Video Record/
Point Cloud Record)
11. Playback
12. Switch Coloring Coding
(point cloud view)
