Technical Specification
CD/MP3 PLAYER SECTION
Signal to Noise Ratio - > 60dB
Channel Separation - > 50 dB (1kHz)
Frequency Response - 20Hz - 20 kHz
TUNER (FM)
Frequency range - 87.5-108 MHz
Intermediate frequency - 10.7 MHz
Sensitivity - 2,8 mV
Stereo separation - 35 dB
Signal to noise radio - 55 dB
Channel step - 50 kHz
TUNER (MW)
Frequency range - 522-1620 KHz
Intermediate frequency - 450 kHz
Usable Sensitivity - 40 dBµV
LINE-OUT
Output - 1000mV
Impedance - 10kOhm
GENERAL
Power Supply - 13.8V DC (10.8-15.6V allowable)
Speaker impedance - 4 or 8 ohm
Output power - 85 watts x 4 ch P.M.P.O. (peak music power output)
17 watts x 4 ch RMS power output
Disposal advice
When the operating life of this device has ended it must not be
disposed as domestic waste, but in accordance with national
environmental guidelines.
21
