DK-1100A Ink Roll Coder Operation Manual
3.1.7 Interfaces for External Signal, Encoder and Fault Output Signal
1
0
Interface for power:
Interface for sensor:
Interface for drive:
Mark Description Color
EARTH
LIVE
NEUTRAL
Double
Color
Red
Black
AC~220V
2
3 1
2
3
1
4
5
6
7
SENSOR
DRIVER
L
M
Wire No .
Description
Color
Wire No .
Description
Color
External print signal 0V
External print signal
Output power of external print
signal +12V
1
2
3
Blue
Black
Brown
1
2
3
4
5
Heating tube exchange pin 1
Heating tube exchange pin 2
Solenoid magnet pin 1
Thermocouple negative
Solenoid magnet pin 2
Red
Red
Brown
Black
Yellow
Thermocouple compensation
pole
6
7
White
Thermocouple positive
Blue
