DK2 Power OPC524 - Parts List

OPC524 man. v.210518 | 17
ENGLISH
NO. DESCRIPTION QTY.
60 6 Spring Washer 1
61 3/8-40 Bolt 1
62 10 Spring Washer 1
63 Ø10*Ø30*3 Washer 1
64 M8*25 Bolt 1
65 8 Spring Washer 1
66 8 Washer 1
67 5*5*50 Key 1
68 M10 Lock Nut 1
69 10 Spring Washer 1
70 10 Washer 1
71 M8 Lock Nut 1
72 M8*30 Bolt 1
73 M8*50 Bolt 1
74 M10*40 Bolt 1
75 M10 Nut 1
76 M8*20 Bolt 1
77 M8*55 Bolt 1
78 Ribbon 1
79 M4*15 Bolt 1
80 4 Spring Washer 1
81 4 Washer 1
82 Buckle 1
83 M4 Lock Nut 1
84 M10*25 Bolt 1
85 M14 Lock Nut 1
86 14 Spring Washer 1
87 Ø16*Ø30*2 Washer 1
88 M10*65 Bolt 1
89 Ø8*70 D-Pin 1
90 M12*65 Bolt 1
91 M8*65 Bolt 1
92 M12*60 Bolt 1
93 12 Washer 1
94 12 Spring Washer 1
95 M12 Lock Nut 1
96 Buckle 1
97 M5*15 Bolt 1
98 M8*25 Bolt 1
99 8 Plastic Washer 1
100 Pin 1
PARTS
PARTS LIST
NO. DESCRIPTION QTY.
1 Belt Cover 1
2 Belt 1
3 Drive Pulley 1
4 Drum Pulley 1
5 Spacer 1
6 Bearing 1
7 Seal Plate 1
8 Inner Belt Cover 1
9 Spacer 1
10 Engine 1
11 Switch 1
12 Switch Seat 1
13 Infeed 1
15 Infeed Extension 1
16 Rubber Fitting 1
17 In-Feed Rubber 1
18 Engine Plate 1
19 Plastic Buckle 1
20 Infeed Damping Pad 1
21 Main Frame 1
22 Anvil Pacing Bar 1
26 Tire 1
27 Oil Seal 1
28 Bearing 1
29 Flange 1
31 Tire Axle 1
33 Anvil 1
34 Blade 1
35 Drum 1
37 Arch Board 1
38 Discharge Damping Pad 1
39 Discharge Fastener 1
40 Discharge Regulator 1
41 Discharge Top Part 1
42 Discharge Bottom Part 1
43 Tower Bar 1
44 Foot Rubber 1
45 Forefoot 1
47 Flange Spacer 1
58 M6*15 Bolt 1
59 6 Washer 1
NO. DESCRIPTION QTY.
101 Tool Box Cover 1
102 Tool Box 1
103 Wire 1
104 Chain 1
105 Tower Hitch 1
106 Front Foot Fitting 1
107 Rubber Pad 1
