OPC524 man. v.210518 | 9
ENGLISH
ASSEMBLY
STEP BY STEP INSTRUCTIONS
STEP 4: INSTALLING THE TOWBAR AND STAND ASSEMBLY
1. Grab the feed chute and tip the unit back, raising the front end up.
2. With the front end raised, install the tow bar hitch using bolts.
3. Assemble tow stand and insert the hitch pin.
4. Lower the unit back to level and rest on the drop stand.
5. Insert the tow bar and secure with tow bar screw lock.
To Next Page
