DKS 1503 - Circuit Wiring Diagram

1503-065-E-3-14 Page 11
1.3 Wiring Diagram
1 2 3 4 5 6 7 8
Master
Code
Electric
Strike
Magnetic
Lock
Gate
Operator
12-24 Volt
AC or DC
Push
to Exit
Electric Strike
Magnetic Lock
Power
1500-010
Circuit Board
