Mile Hao Xiang Technology Co., Ltd
4
Maximum Speed
55KM/H
Starting Mode
Electrical
Spark plug
NGK BPMR8Y
Ignition/Power
CDI ignition/6W
2Body
Hull
Carbon fiber
Size
1800*600*150MM
Maximum Speed
55KM/H
Minimum Water
Depth
50CM
Maximum Load
100KG
Packing Size
1900*700*300MM
3Controller
Model
DLE-ECU
Size
Φ82*125MM
Battery capacity
65Wh
Output voltage
12V
Low-voltage warning
8.5V
4Starter Motor
Motor power
12V/400W
4. Parts description and Precautions
When you received the Jetboard, please take out the stand and
place the board on the stand, and then charge the controller (water
pump and charging are share same connector), you can start to
install the tail/side fin during the charging.
