Specifications
We follow a policy of continuous advancement in
development.
For this reason all or part of specifications & designs
may be changed without prior notice.
15
CA22, 23, 31, 41 & 51
DLS CLASSIC CA 22 CA 23 CA41
Number of channels 2 2 4
RMS power out, 4 ohm (0,1% THD) 2 x 60 W 2 x 135 W 4 x 70 W
RMS power out, 2 ohm (0,2% THD) 2 x 100 W 2 x 200 W 4 x 125 W
RMS power out, 4 ohm bridged 1 x 200 W 1 x 400 W 2 x 200 W
Signal to noise ratio, A-weighted >100 dB >100 dB >100 dB
Damping factor >100 >100 >100
Frequency response 10 Hz - 35 kHz 10 Hz - 35 kHz 10 Hz - 35 kHz
Input impedance, low level >10 kohm >10 kohm >10 kohm
Input impedance, high level 100 ohm 100 ohm 100 ohm
High level input with auto start Yes Yes Yes
Low output (RCA output) Yes Yes Yes
Input sensitivity 0,25 - 5V 0,25 - 5V 0,25 - 5V
Grand bass adjustable frequency - 25 Hz - 80 Hz 25 Hz - 80 Hz
Grand bass adjustable gain 0 - 18 dB 0 - 18 dB 0 - 18 dB
Filter highpass /subsonic 15-500 Hz* 15-150 Hz* see spec. below
Filter lowpass 50-500 Hz* 50-500 Hz* see spec. below
* can be switched in/out
Power consumption, idle 0,5 A 0,7 A 1,0 A
Fuse 1 x 25 A 2 x 30 A 2 x 30 A
Dimensions HxWxD(mm) 67x212x250 67x295x250 67x354x250
Dimensions (inch) 2,63x8,35x9,84 2,63x11,6x9,84 2,63x13,93x9,84
Weight 2,5 kg 3,6 kg 4,2 kg
DLS CLASSIC CA 31 CA51
Number of channels 3 5
RMS power out, 4 ohm (0,1% THD) 2 x 65 W 4 x 50 W
RMS power out, 2 ohm (0,2% THD) 2 x 90 W 4 x 80 W
RMS power out, 4 ohm bridged 1 x 170 W 2 x 150 W
Power out mono sub ch. 4 ohml 1 x 170 W 1 x 150 W
Power out mono sub ch. 2 ohm 1 x 280 W 1 x 225 W
Signal to noise ratio, A-weighted >100 dB >100 dB
Damping factor >100 >100
Frequency response 10 Hz - 35 kHz 10 Hz - 35 kHz
Input impedance, low level >10 kohm >10kohm
Input impedance, high level 100 ohm 100 ohm
High level input with auto start Yes Yes
Low output (RCA output) No No
Input sensitivity 0,25 - 5V 0,25 - 5V
Variable phase shift control 0-180 degrees 0-180 degrees
Filter highpass CH A & B 50-150 Hz* see spec.
Filter lowpass CH C / E 50-120 Hz* see spec.
Subsonic filter CH C / E Fixed 25 Hz* Fixed 25 Hz*
* can be switched in/out
Power consumption, idle 1,0 A 1,0A
Fuse 2 x 30 A 3 x 30 A
Dimensions HxWxD(mm) 67x340x250 67x419x250
Dimensions (inch) 2,63x13,38x9,84 2,63x16,5x9,84
Weight 4,2 kg 5,3 kg
Filter configuration CA41
Channel A/B:
Highpass: 15 - 500 Hz*
Lowpass: 50(500) - 500(5k) Hz*
(x 10 switch)
Channel C/D:
Highpass: 15(150)Hz - 500(5k)Hz*
(x 10 switch)
* can be switched in/out
Filter configuration CA51
Channel A/B:
Highpass: 15 - 500 Hz*
Lowpass: 50(500) - 500(5k) Hz*
(x 10 switch)
Channel C/D:
Highpass: 15(150)Hz - 500(5k)Hz*
(x 10 switch)
Channel E:
Lowpass 60 Hz - 120 Hz
Subsonic fixed 25 Hz*
* can be switched in/out
All above output power
ratings at 13,8 VDC
