DMG Raffaello 2.8 - 3.3 Parallel Wiring (1 WIRE; SEGMENT); Protocol Setting (1 Wire; Segment); Car or Floor Position Indicator Setting; Common Input Setting

D I S P L A Y
10
2,8"2,8"
Liaison 1 fil par segment • 1 Draht je Segment Protokoll • Protocolo 1 hilo por segmento
Collegamento in parallelo (1 FILO / SEGMENTO) • Parallel wiring (1 LINE / SEGMENT)
3.3
A
X08
X01
X02
X03
X04
X05
X06
X07
Decine / Tens Unità / Unit
X10
X09
max 29 piani (-9, 0, 19)
max 29 floors (-9, 0, 19)
maxi 29 niveaux (-9, 0, 19)
max. 29 Etagen (-9, 0, 19)
máx 29 pisos (-9, 0, 19)
B
Impostazione protocollo • Protocol setting
C
Impostazione display di cabina (COP) o di piano (LIP/LOP) • Car (COP) or floor (LIP/LOP) position indicator setting
PRG
Input
1 Wire per Segment
D
Impostazione comune ingressi • Inputs common setting
§ 3.2
§ 3.2
PRG
ADV
X01 X09 X10 X02 X03 X04 X05 X06 X07 X08
DISPLAY INPUT
POWER
SUPPLY
S4 S1 S2
UP
DOWN
COM S
PARALLEL
12/24Vdc12/24Vdc
Piani / Floors
Frecce / Arrows
12/24V DC
PRG
ADV
Programming MENU
DK3RF100M.F
