Datasheet

Raffaello 2″

Dimensions

62×68 mm (STD)

62×76 mm (DZ1)

55×68 mm (D1)

Screen 40,8×30,6 mm / 320×240 pixel

Power supply (position input) 12÷24V DC ±10%

Absorption 12V DC: Max 49mA • 24V DC: Max 36mA

Indicators inputs

S4:

12÷24V DC ±10%

Operating temperature -10°C ÷ +50°C

Video Tutorial

2) Set up Floor Numbers / Letters
