DMG RAFFAELLO User Manual

(*) – Service messages can also be piloted, through serial bus, in two different ways:
by controller DMG
by encoder DEUM.M15
Settings
Setup Key Exit / Back Access Menu Key Value setting (>3 sec.)
Navigation menu keys
The display navigation menu is in English only; to see the correct menu items we recommend setting the DIDO
website language to English.
MENU MENU ITEM AVAILABLE CHOICES INPUTS
Parallel CANBUS
Input
Serial / 1 wire per floor / segment
Gray / Binary / Pos.Sensor
TKE / MEA / Autinor / CAN DMG
• •
Options Interface
Options
Arrow Configuration Direction / Next Dir. •
Car at Floor No / Yes •
CAN Baudrate 250k, 125k, 10k, Auto •
Convert Mezzanine No / Yes •
Offset Value -9 / ... / 0 / ... / +9 •
General

DMG RAFFAELLO Specifications

General

Brand	DMG
Model	RAFFAELLO
Category	Monitor
Language	English
