DMP Electronics EBOX-3350MX - System Specifications

6
System Specification
CPU
Vortex86MX (933 MHz)
(System on Chip)
Main Memory
512MB DDR2 (16-bit DRAM bus)
BIOS
AMI BIOS
VGA
Resolution up to 1600 x 1200 High Colors
Peripheral
1. USB V2.0 x 3 (2 at front, 1 at rear)
2. SD card slot x 1
3. Audio (Mic In, Line Out)
4. RS-232 port x 2
(Available in EBOX-3500MX-C2/C2AP)
Dimension & Weight
EBOX-3500MX/AP
95 x 95 x 20 mm / 277g
EBOX-3500MX-C2/C2AP
95 x 95 x 35 mm / 350g
Operating System
Windows XP Home/ Pro.
Windows XP Embedded
Windows Embedded CE
Supported Linux Distribution list:
1. Debian 4.0
2. Debian 5.0
3. Ubuntu 8.04
4. Ubuntu 8.10
5. Ubuntu 9.04
6. Ubuntu 10.04
7. Edubuntu 9.04 (Ubuntu 8.10 base)
8. Easy Peasy 8.10
9. Puppy 4.2.1
10. Puppy 4.1.2
11. WattsOS2 Warp30 (Ubuntu 8.10 base)
※ Red letters: Standard IDE compatible option
enable could help for install directly
※ Ubuntu 8.10 / WattOS, Remember to enable
the Media Port Instruction option for VGA
compatible. Resource (Kernel/Drivers Package):
