Digital Monitoring Products
*No Bell Circuit or LED alarm status **Bell Circuit and LED alarm status
Programming Option Table
PROGRAMMING INFORMATION
For 740, 741, and 743 SC Series Keypad
Bus address _ _ (00 to 99)
LX-Bus Comm. _ (0,1, or 4)
Bell Cutoff _ _ (00 to 15 min.)
Exit Delay _ _ (00 to 99 sec.)
Entry Delay _ _ (00 to 99 sec.)
Zone # Type Description
Zone 1 Perimeter Entry/Exit
Zone 2 Perimeter Instant
Zone 3 Interior Instant
Zone 4 Fire or Panic
Alarms on internal speaker ❑ NO ❑ YES
Panic Keys ❑ NO ❑ YES
Zone 4 Operation (Panic or Fire) _ (1, 2, or 3)
Relay Operation (741 & 743 only) _ (1 to 3)
Battery Test ❑ NO ❑ YES
Option # 740 741 743 Keys Pressed Description Range Default
1 X X X SPECIAL,0,1 Programming Initialization 0=No, 1=Yes 0
2 X X X SPECIAL, 0,2 Clear User Codes 0=No, 1=Yes 0
3 X X X SPECIAL,0,3 Bus Address 00-99 00
4 X X X SPECIAL,0,4 LX-Bus Communication Style 0=None, 1=711, 4=714 1
5 SPECIAL,0,5 For future use
6 SPECIAL,0,6 For future use
7 X X X SPECIAL,0,7 Bell Cutoff Time 00-15 Minutes 05
8 X X X SPECIAL,0,8 Exit Delay Time 00-99 Seconds 60
9 X X X SPECIAL,0,9 Entry Delay Time 00-99 Seconds 30
10 X X X SPECIAL,1,0 Alarms on Internal Speaker 0=No, 1=Yes 1
11 X X X SPECIAL,1,1 Panic Keys Enabled 0=No, 1=Yes 0
12 X X X SPECIAL,1,2 Zone 4 Operation (Panic or Fire) 1=Panic*, 2=Panic**, 3=Fire 1
13 N/A X X SPECIAL,1,3 Relay Operation 1=Alarm, 2=Access, 3=Sensor Reset 1
14 N/A X X SPECIAL,1,4 Battery Test Enabled 0=No, 1=Yes 0
15 SPECIAL,1,5 For future use
99 X X X SPECIAL,9,9 Set Programming Access Code 0000-9999 0000
00 X X X SPECIAL,0,0 Exit Programmer Mode 00 N/A
