DMTech FP9000L-2 - Technical Parameters; Line Parameters and Thresholds; Panel Output Specifications

Instructions for installation, setup and operation - FP9000L-2/4/6/8
Page 3 of 16
1. INTRODUCTION
FP9000L-2/4/6/8 is a conventional Fire alarm panel with 2, 4, 6 or 8 lines. Certified to standards
EN 54-2 and EN 54-4. Each line can be connected to 32 detectors. The panel has 4 relay outputs, 2 of
which are controllable and one relay. The outputs may have a delay of seven minutes. Panel to add and
expansion relay module M9000R - 2/4/6/8.All the panel conditions information is LED indicators.
Quick and easy - installation, setup and starting. Simple and clear procedures for operation
and maintenance of the system.
2. TECHNICAL PARAMETERS
LINES
 Lines:
 Number of lines
2,4,6 or 8
Optional
 Maximum number of fire detectors in a line
32
 Type of the joining line
biconductional
 Plume maximum resistance
100 
 Current thresholds in the lines:
 Interruption
from 1 to 4 mA
 Duty mode
from 4 to 16 mA
 Fire
from 17 to 70 mA
 Fire direct /without delay outputs/
from 40 to 70 mA
 Short circuit
> 70 mA
 Lines functional characteristics:
 Verification quantity before entering Fire
mode:
2
 Verification and regestrating fault in a earth
conductor
yes
selectively
OUTPUTS
 Independent relay output in case of fire alarm:
 Quantity
1
 Type
switching
NC / NO
 Electrical characteristics
3А/125V AC,
3A/30V DC
 Controllable output in case of fire alarm:
 Quantity
2
 Type
potentional relay
 Electrical characteristics
(19-28)VDC/ 0,5A
 Additional relay outputs (modul M9000R 2/4/6/8) in case of fire alarm:
 Quantity
2/4/6/8
 Type
potentional-free
NO
