DNP DS620 - Installation Precautions; Installation Environment Guidelines; Cable and Connection Safety

1
2
3
4
5
6
7
8
9
10
11
Use the opening lever to
open the lock, and then
pull out the mechanism
unit.
Remove the paper holder
from the printer.
Connect the power cord
(supplied) and the USB
cable, and make sure that
the ON/Standby switch of
the printer is turned ON.
Lift the paper lever, raise the front
cover and remove the scrap box.
Set the paper roll on
the paper holder.
Set the roll so that
there is no gap
between the paper
and the holder.
Set the paper holder in
the printer, and then
rotate the roll in the
direction of the arrow.
Insert the leading edge
of the paper until you
hear the buzzer sound.
The flashing LED
(orange) turns off.
Opening lever
ON/Standby
switch
Scrap box
Paper tray
Scrap box
Paper lever
Front cover
Hold the paper holder to
prevent it from turning
when rotating the paper.
Set the scrap box and
close the front cover.
Remove the ribbon
cassette from the
printer unit.
Set the new ribbon into
the ribbon cassette.
Rotate the roller in the
direction of the arrow
to take up the slack.
12
Install the printer driver.
For more information, refer to "Printer Driver User’s
Manual" including in the supplied CD-ROM.
Install the ribbon
cassette to the printer
unit.
Close the mechanism
unit.
13
Connect the printer to the computer with a USB
cable.
When using L or PC size paper, you may install the paper
tray to the scrap box.
When the mechanism unit is closed, the printer starts
paper initialization. (Five blank sheets are output.) Paper
initialization cuts off the outer layer of the paper that may
be dirty. Note that paper initialization is not carried out if
the printer ON/Standby switch is set to ON after the paper
is set.
Take-up
side
Supply
side
Install the cassette so
that the supply side is
at the front.
Printer installation
Checking the contents
Printer unit
Power cord
Ribbon
cassette
Paper holder
Paper tray
(for L and PC sizes)
L size spacer
Explanation booklet (this document)
For Safe Operation
Start up guide
CD-ROM
Printer Driver User's Manual
Paper tray installation
Make sure that the scrap box is installed when printing.
If not installed, your fingers may get caught in the moving
parts and be injured.
Caution
Caution
• Do not install the product in dusty or humid places. This may cause re or an electric shock, or damage the
product.
• Do not install the product on an unstable surface. It may fall and cause injury to the user or other people.
• Do not allow foreign objects to enter into the product. They may cause an electric shock, a short circuit, a re,
or damage the product. If something falls into the product, immediately unplug the power cord, and then call a
service representative.
• Do not open the cover while printing. This may damage the product.
• Do not spill or spray liquids or chemicals onto the product.
• When cleaning the cover, do not use thinner, trichloroethane, benzene, ketone-based cleaners, or chemically
treated cloths. They could discolor or deteriorate the cover.
• At least once a year, unplug the power cord, and clean the prongs and the plug. If dust accumulates, it may
cause a re.
• When printing continuously for long periods in a small room, be sure to ventilate the room properly.
• If you intend to use the product on a transportation vehicle (train, truck, ship, etc.), please talk to a representative
in advance.
• When disposing of the product, accessories, packaging materials, or media (paper, ribbon), please abide by
local waste removal ordinances. For details, contact your local government ofces.
• When unplugging the cord, always grip the plug. Do not pull on the cord as it may damage the cord and cause
an electric shock or re.
• When moving the product, be sure to unplug the power cord. Otherwise, the cord may be damaged, which may
cause re or an electric shock.
• For safety, when not using the product for an extended period of time, be sure to unplug the power cord.
Otherwise, it may cause an electric shock, re, or a malfunction.
• Parts with this warning get extremely hot. Do not touch these parts after printing. There is a danger of burns.
• Do not touch the gear mechanisms. There is a danger of injury if ngers get caught in spinning gears.
Caution for installation
• Before using the product, read “For Safe Operation” carefully and observe the instructions therein.
• Use care when moving the product. Never try to carry the product alone. Dropping it may cause injury or property
damage.
• Do not use or store the product near a re, humid places, in direct sunlight, near an air conditioner or heater, or any other
location with unusually high or low temperature, strong humidity, or excessive dust.
• Do not place the product where chemical reactions occur, such as in a laboratory.
• Do not install the product where there is salinity or corrosive gas in the air.
• The product must be installed on a rm, level surface where there is ample ventilation.
• Do not put anything on top of the product.
• Do not use the product near a radio or television, and do not use the same wall outlet for the product and a radio or
television. Otherwise radio or television reception may be adversely affected.
• Do not use a power voltage or a frequency other than those specied.
• Do not put anything on the power cord or step on it.
• Do not drag or carry the product by the power cord or the USB cable.
• Avoid plugging the power cord into an outlet with many other cables connected.
• Do not bundle the power cord.
• Always grip the plug housing, not the cord, to plug or unplug the power cord.
• Always unplug the power cord before connecting or disconnecting the USB cable.
• Avoid using a long USB cable or connecting it to any noise-producing device. If it is unavoidable, use a shielded cable or
twisted pair for each signal.
• Use a shielded USB cable compatible with the USB 2.0 specications.
• Place the product near the outlet where the power cord can be unplugged easily to shut the power off.
• Use an AC outlet that accepts a three-pronged plug. Otherwise, there may be a danger of electric shock.
• Do not use the cord set supplied with the printer for other devices.
• Use the cord set supplied for the product.
• This product is not intended for use in the immediate/direct visual eld of the display work place. To avoid disturbing
reections on the display work place, this product shall not be placed in the immediate/direct eld of vision.
• Use as a network printer is not anticipated. Any use in conjunction with a network will be the customer’s sole
responsibility.
Specications
Print method Thermal dye sublimation transfer Rated current 100 V 3.9 A 240 V 1.6 A
Dimensions 275 mm(W) × 366 mm(D) × 170 mm(H)
Operating
environment
Temperature 5°C to 35°C
in natural convection conditions
Weight Approx. 12 kg (printer unit only)
Rated voltage AC100 V – 240 V 50 Hz/60 Hz Humidity 35% to 80% with no condensation
