The resulting top view of the instrument is as shown in Figure 4.23.
Figure 4.23 M4100 Interior View
Transformer
Cover
ground)
Amplifier Assembly
(chassis ground)
Transformer
(connected
to guard)
(chassis
Main Reference Assembly
(connected to guard)
Card
Cage
Low Voltage Power Supply Board
(under corner brace)
