17
Camera Settings
G-Sensor
The G-Sensor measures shock forces. The settings
from “low to high” determine the amount of force
needed to lock the file from being overwritten.
Recommended Setting: Low
Loop Recording
Loop recording can be set to 2, 3 or 5 minutes.
Video recordings of the selected length will be
recorded onto the memory card. When the memory
card is filled the oldest files will be overwritten
(excluding locked clips). Turning off loop recording
will prevent the camera from writing new files when
the memory card is filled.
Motion Detection
For use when parked not when driving. Saves
memory space by only recording when motion is
detected. Motion detection must be manually
disabled before driving.
If motion detection is activated while driving you
may have significant gaps in the recorded video.
Time-lapse
The time-lapse function is used to create a fast-
forwarded video. When set, the camera will record
one frame every 200 ms (milli-seconds) / 500ms / 1
second / 5 seconds. This feature should be turned
off during regular driving.
Speed Units
Select Metric or Imperial units.
Standby Speed Display
After a customized period of time a new screen will
appear showing speed and direction. If enabled, the
GPS speed warning will appear on this screen.
WDR (Wide Dynamic Range)
Cannot be changed. Shows WDR processing is
enabled.
White Balance
Sets the white balance.
Recommended Setting: Auto
World Time Zone
Sets the current time zone for GPS time and date
calibration. Note the time zone must be manually
adjusted for daylight savings.
