The Integrated Power Module is located in the engine compartment near the battery.
This center contains cartridge fuses and mini fuses. A description of each fuse and
component may be stamped on the inside cover, otherwise the cavity number of each
fuse is stamped on the inside cover that corresponds to the following chart.
Cavity Cartridge Fuse Mini Fuse Description
J01 40 Amp Green Trailer Tow
J02 30 Amp Pink Electric Brake
J04 25 Amp Natural Driver Door Node
J05 25 Amp Natural Passenger Door Node
J06 40 Amp Green Antilock Brakes Pump/Stability
Control System
J07 30 Amp Pink Antilock Brakes Valve/Stability
Control System
J08 40 Amp Green Power Seat
J09 40 Amp Green Flex Fuel
J10 30 Amp Pink Sway Bar Equipped Module –
If Equipped
J11 30 Amp Pink Transfer Case Module
J12 30 Amp Pink Rear Defroster
J13 60 Amp Yellow Main Ignition Off Draw (IOD) Fuse
J14 20 Amp Blue Trailer Tow Lamps/Park Lamps
J15 40 Amp Green Front Blower
J17 40 Amp Green Starter Motor Solenoid
J19 60 Amp Yellow Rad Fan Motor HI/Rad Fan
Motor Low
J20 30 Amp Pink Front Wiper Ground/Low/High
J21 20 Amp Blue Washer Control
J22 25 Amp Natural Sunroof Module
M1 15 Amp Blue Stop Switch Lamp
M5 25 Amp Natural 115V AC Inverter
M6 20 Amp Yellow Power Outlet (Instrument Panel or
Front Console)/Rain Snsr
M7 20 Amp Yellow Power Outlet (Rear Console or
Center Seat)
M8 20 Amp Yellow Front Heated Seat & Steering Wheel
M9 20 Amp Yellow Rear Heated Seats
M10 15 Amp Blue Hands Free Module/Vanity Lamp/
Universal Garage Door Opener
Module
M11 10 Amp Red Climate Control System
M12 30 Amp Green Radio/Amplifier
