Cavity Cartridge Fuse Mini Fuse Description
M13 20 Amp Yellow Main #2 Instrument Cluster/
Wireless Control Module/ITM/Siren/
Multifunction Switch (Steering
Column Module)
M14 20 Amp Yellow Back Up Camera (Domestic Only)
M15 20 Amp Yellow Power Seat Module(s)/Audio
Telematics/Daytime Running Lights
Relay/Instrument Cluster/Transfer
Case Module
M16 10 Amp Red Airbag Module
M18 15 Amp Blue Center Stop Lamp
M19 25 Amp Natural Automatic Shutdown 1 and 2
M20 15 Amp Blue Instrument Cluster Interior Lighting/
Sw Steering Wheel/Sw Bank
M21 20 Amp Yellow Automatic Shutdown 3
M22 10 Amp Red Horns (Low/High) – Right
M23 10 Amp Red Horns (Low/High) – Left
M25 20 Amp Yellow Fuel Pump Motor/Diesel Lift Pump –
If Equipped
M26 10 Amp Red Driver's Door Switch
M27 10 Amp Red Ignition Switch
M28 15 Amp Blue Powertrain Control Module
M29 10 Amp Red Tire Pressure Monitor
M30 15 Amp Blue J1962 Diag Connector
M31 20 Amp Yellow Back-Up Lamps
M32 10 Amp Red Airbag Module
M33 10 Amp Red Powertrain Control Module
M34 10 Amp Red Park Assist Module/Climate Control
System Module/IR Sensor/Compass
Module
M35 15 Amp Blue Left Front & Rear Parklamps
M36 20 Amp Yellow Power Outlet (Instrument Panel or
Center Console)
M37 10 Amp Red Antilock Brakes/Stability Control
System Module/Stoplamp Switch
M38 25 Amp Natural All Door Lock & Unlock
MAINTAINING YOUR VEHICLE
143
