Engine/Transmission GCWR (Gross Com-
bined Wt. Rating)
Frontal Area Max. GTW (Gross
Trailer Wt.)
Max. Tongue Wt.
3.8L Automatic with
trailer tow package
8,600 lbs (3 900 kg) 40 SQ. FT. (3.72
square meters)
Up to 2 persons &
Luggage 3,800 lbs
(1 723 kg)*
380 lbs (172 kg)
8,600 lbs (3 900 kg) 40 SQ. FT. (3.72
square meters)
3 to 5 persons &
Luggage 3,350 lbs
(1 519 kg)*
335 lbs (152 kg)
8,600 lbs (3 900 kg) 40 SQ. FT. (3.72
square meters)
6 to 7 persons &
Luggage 3,000 lbs
(1 360 kg)*
300 lbs (136 kg)
* For vehicles equipped with Fold-in-Floor seating, the Gross Trailer Weight must be reduced by 100 lbs (45 kg).
Refer to local laws for maximum trailer towing speeds.
NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo,
and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to the
Tire–Safety Information Section in this manual.
376 STARTING AND OPERATING
