Cavity
Cartridge
Fuse
Mini
Fuse
Description
J1 40 Amp
Green
—
Power Folding Seat
J2 30 Amp
Pink
—
Power Liftgate Mod-
ule
J3 40 Amp
Green
—
Rear Door Module
(RR DOOR NODE)
J4 25 Amp
Natural
—
Driver Door Node
J5 25 Amp
Natural
—
Passenger Door Node
J6 40 Amp
Green
—
Anti-Lock Brake Sys-
tem (ABS) Pump/ESP
J7 30 Amp
Pink
——
J8 40 Amp
Green
—
Power Memory Seat
(If Equipped)
Cavity
Cartridge
Fuse
Mini
Fuse
Description
J9 40 Amp
Green
—
PZEV Motor/Flex
Fuel
J10 30 Amp
Pink —
Headlamp Wash
Relay/Manual Tuning
Valve
J11 30 Amp
Pink
—
Power Sliding Door
Module
J13 60 Amp
Yellow
—
Ignition Off Draw
(IOD) — Main
J14 40 Amp
Green
—
Rear Window Defog-
ger
J15 30 Amp
Pink
—
Rear Blower
J17 40 Amp
Green
—
Starter Solenoid
