FLUID CAPACITIES

U.S. Metric

Fuel (Approximate)

2500/3500 Standard Cab Longbed Models 28 Gallons 106 Liters

2500/3500 Crew/Mega Cab Shortbed Models 31 Gallons 129 Liters

2500/3500 Crew Cab Longbed Models 32 Gallons 132 Liters

Standard Rear Tank – Chassis Cab Only 52 Gallons 197 Liters

Optional Midship Tank – Chassis Cab Only 22 Gallons 83 Liters

Diesel Exhaust Fluid Tank (Approximate) –

2500/3500 Models

5.5 Gallons 21 Liters

Diesel Exhaust Fluid Tank (Approximate) –

Chassis Cab

9 Gallons 34 Liters

Engine Oil With Filter

6.7L Turbo Diesel Engine 12 Quarts 11.4 Liters

Cooling System

6.7L Turbo Diesel Engine (MOPAR Engine

Coolant/Antifreeze 10 Year/150,000 Mile

Formula)

5.7 Gallons 21.4 Liters

204 MAINTAINING YOUR VEHICLE
