Dolphin DAS400 - Technical Specification

14
Voltage 12VDC
Power 3.6W
Frequency 40KHz
WorkingTemperature -20ºCto70ºC
DetectingDistance 0.3m–2.0m(seetablebelow)
DetectingAngle H>60V>60
Frequency 315MHz/433MHz
SizeofProcessor 96mmx68mmx26mm
SizeofUltrasonicRecessSensors 25mmx22mm
DiameterSizeForDrilling-Standard 21mm(DrillBitSupplied)
DiameterSizeforDrilling-Micro 18mm(DrillBitSupplied)
LengthofRearSensorsCabling 2.5m
LengthofFrontSensorsCabling 6m
SizeofBuzzer 59mmx40mmx17mm
LengthofCablingforBuzzer 2m
SizeofDPS650/850Display 100mmx20mmx26mm
LengthofCablingforDisplay 6m
CMOSCameraAngle 120º
Stage Distance Awareness Alarm
1 200-160cm SafeMode No
2 150-100cm AwarenessMode Bi---Bi---Bi
3 90-50cm AlarmMode Bi--Bi--Bi
4 40-30cm DangerMode Bi-Bi-Bi
5 30–0cm Stop Bi------
TECHNICAL SPECIFICATION
