Dolphin DAS400 - Installation of DMS 600;650;655

7
Thisdiagramisfortting6Micro
sensorsattherearofthecarwith
eitherabuzzer(DMS600),dashboard
display(DMS650)orrearroofdisplay
(DMS655).
TheMicrosensorshaveaslightangle
mouldedintothemandshouldbe
ttedtofaceslightlyup.Theouter
sensorsAandFarelesssensitive
andaredesignedtobemountedon
thesidesofthebumpertocoverthe
coverswiththemiddlesensorsB–E
coveringtherear.
Forthe600audioonlybuzzermodels,
thisispluggedintothesocketmarked
DISP.Thisisaloudbuzzerandon
mostcars,certainlyhatchbacksand
estates,thiscanbemountedinthe
bootcompartmentandeasilybeheard
atthefrontofthecar.
Ifyouhavethe650ora655display
systemthebuzzerisbuiltintothe
backofthedisplayandisnota
separateitem.Thedisplayisona6m
cable,the650displayisdesigned
tobemountedonthedashboard.
The655displayisbothinvertedand
reectedsoitcanbereadbackwards
throughyourreversingmirrorandis
designedtobemountedtotheroofin
therearofthevehicle.SensorsA,B,C
arerelativetoonesideofthedisplay
andD,E,Ftheothersidetoindicate
whichsideisclosesttoanobjectwith
adigitalcountdownin10cmunitsin
themiddleofthedisplay.
INSTALLATION OF 6 SENSOR REAR KIT
DMS 600/650/655
