Thisdiagramisfortting6Micro
sensorsatthefrontofthecarwith
eitherabuzzer,600F,ordashboard
display,650F.
TheMicrosensorshaveaslightangle
mouldedintothemandshouldbetted
tofaceslightlyup.Theoutersensors
AandFarelesssensitiveandare
designedtobemountedonthesidesof
thebumpertocoverthecoverswiththe
middlesensorsB–Ecoveringtherear.
The600F/650Fissuppliedwithlonger
6msensorstotaroundtheengine
bay.Thesensorcablingshouldberun
downtheoppositesideoftheengine
baytowherethebatteryissituatedto
avoidelectricalinterference.TheBrain
boxshouldbemountedunderneath
thedashboardbutawayfromthefuse
boxandanythingelselikelytocause
electricalinterference.
Arockerswitchissuppliedforyouto
manuallyturnthefrontsensorsonas
andwhenyouneedthem.Thisshould
beconnectedtoanignitionswitched
feed,thatisapowersourcethatislive
whenthecarison,suchasthecar
stereosystem.Alternativelyyoumaylike
tovisityourlocalcardealerships’parts
departmenttogetablankswitchthat
matchesthedesignoftheotherson
yourdashboard.
OptionallyifyouhaveamodernCANBus
wiredcaryoumayhaveadditionally
purchased(orcanpurchase,seeSpares
&Accessories)aCANBusinterface
thatwilltakeaspeedreadingfor
thecarsenginemanagementsystem
andautomaticallybringthesensors
onwheneveryourspeedisbelow
approximately6mph.
INSTALLATION OF 6 SENSOR FRONT KIT DMS 600F/650F
