• V+/V-
These terminals will supply power to the transmitter.
• RF1
Channel 1 terminal
• NO (Normally open)
Use N.O. for equipment that requires a temporary surge of
electricity to activate. Example, Electric door locks, automated
gates, push plates, etc.
• COM
Common ground
•
NC
(Normally closed)
Use N.C. for equipment that requires a constant flow of
electricity to function properly. Example, Magnetic locks,
receivers, etc.
• BATTERY 6VDC
If deciding to power the DOL1000-MF with a battery, then
connect the battery to these terminals.
• 6-24VAC/DC
If deciding to hardwire the DOL1000-MF directly to a power
source, use these terminals.
• Master Reset Button
Holding this button down for 5 seconds reconnecting to its
power source will make the keypad beep 3 times. This will
indicate that the Master Code has been reset to 1234.
